Metal injection molding MIM process advantage

Metal injection molding MIM process advantage

Advantage 1: Very high design freedom

Compared to other metal forming methods, metal injection molding MIM parts can make more complicated parts. Basically, all structures that injection molds can be achieved can be used on MIM

Advantage 2: More material selection

Metal injection molding MIM parts can be used in almost most of the metal materials. Considering economics, the main application materials include iron -based, nickel -based, copper -based, titanium alloy or alloy.

Advantage 3: excellent physical and chemical performance

Metal injection molding MIM parts are very close to the theoretical density because the sintering density is very close to the theoretical density, and its physical and chemical performance is also very good. For example, the mechanical strength has greatly surpassed traditional powder metallurgy.

Advantage 4: Exquisite appearance performance

Metal injection molding MIM parts sintering blank surface roughness (RA) can achieve 1 μm, and it can also obtain a dazzling appearance effect through various surface treatment methods.

Advantage 5: higher size accuracy

Metal injection molding MIM parts can generally achieve ± 0.5%of the tolerance accuracy. With other processing methods, higher size accuracy can be obtained.

Advantage 6: Powerful and flexible mass production capabilities

Metal injection molding MIM parts can be flexibly adjusted and rapidly increased production. From hundreds of pieces to hundreds of thousands of daily to more than hundreds of thousands of daily.

Advantage 7: Environmental protection processing concept

The raw material utilization rate is close to 100%, which is a near -net forming technology that can effectively avoid waste of materials.
