Φ10 Swivel Welded Wire Rope End Fitting Assembly

The Φ10 swivel welded wire rope end fitting assembly is a critical rigging component used in lifting and hoisting operations, connecting steel wire ropes to other load-bearing components.

The following is a detailed description:
One of the core parameters of this end fitting assembly is "Φ10," which refers to the nominal diameter of the compatible steel wire rope, which is 10 millimeters. This determines its compatibility with specific wire rope specifications and its basic load-bearing capacity. The "swivel" design is a significant feature, meaning that the main body of the end fitting assembly (usually the end piece with the connecting device) can rotate or swing at a certain angle relative to the connected component. This swivel characteristic greatly enhances its adaptability in complex working conditions, effectively preventing torque concentration and excessive bending stress on the wire rope due to rigid connections during lifting operations. It also allows the lifted object to adjust its posture within a certain range, improving operational flexibility and safety.

"Welded" specifies the connection process between the end fitting assembly and the wire rope. During manufacturing, one end of the wire rope is disassembled into strands according to the specified length, and then inserted into or wrapped around the specific welding area of ​​the end fitting assembly (such as a sleeve, lifting ring base, etc.). Welding (such as arc welding, gas shielded welding, etc.) is then used to firmly fuse the metal components with the wire rope strands or core, forming a permanent connection. The welding process ensures high connection strength between the end fitting assembly and the wire rope, guaranteeing that it will not detach or break under rated load, which is a critical link in ensuring the safety of the entire lifting system.

This assembly typically consists of a welded rope socket (or rope end metal part), a swivel connecting component (such as a universal joint, swivel ring, or lifting ring with bearings), and possible auxiliary fastening or protective parts. Its overall structure is carefully designed and calculated for strength to ensure stability and reliability under tensile, bending, and other loads.

The Φ10 swivel welded wire rope end fitting assembly is widely used in various industrial lifting, construction, port handling, and equipment installation applications. It can conveniently and safely connect steel wire ropes to objects such as hooks, lifting devices, and hoisted equipment. Its movable function reduces additional stress during the lifting process, protecting the steel wire rope and extending its service life, while ensuring the stability and safety of lifting operations. When selecting and using this device, it is necessary to strictly follow its rated load capacity and conduct regular inspections to ensure that there are no cracks or deformation in the welded parts, and that the movable parts rotate smoothly without jamming, thus guaranteeing operational safety.
