Technical Field

The utility model relates to the technical field of automobile parts, and in particular to an automobile engine base bracket.

Background Technology

The existing automobile engine base bracket has a complex structure and wastes materials. Due to the complexity of the structure, the overall service life is not long, resulting in unnecessary troubles such as maintenance and replacement.

Invention Content

In order to overcome the shortcomings of the above-mentioned prior art, the utility model provides an automobile engine base bracket with a simple structure and a long service life.

The technical solution adopted by the utility model is: an automobile engine base bracket, characterized in that: the bracket body is bilaterally symmetrical, the bracket body is in a disc shape, a rectangular hole is provided in the middle of the bracket body, and a rectangular hole is provided in the middle of the bracket body, one side of which is longer than the opposite side and has an arc-shaped connecting line in the middle. [0005] Preferably, the bracket is made of iron-based metal injection molding.

Preferably, the rectangular hole is chamfered at the right angle.

Preferably, the radius of the arc chamfer is 2mm.

Compared with the prior art, the beneficial effects of the utility model are: simple structure, can save a lot of materials, and have a long service life.

Description Of The Drawings

In order to more clearly illustrate the technical solution of the utility model, the following will briefly introduce the drawings required for the description of the embodiments. Obviously, the drawings described below are only some embodiments of the utility model. For ordinary technicians in this field, other drawings can be obtained based on these drawings without creative work.

Figure 1 is a structural diagram of the utility model.

In the figure: 1. Bracket body, 2. Rectangular hole, 3. Rectangular hole.

Specific Implementation Method

In order to more clearly understand the technical solution of the utility model, the utility model is further described in conjunction with the drawings.

As shown in Figure 1, a bracket for an automobile engine base, the bracket body 1 is symmetrical on the left and right, and the overall shape of the bracket body 1 is disc-shaped. The middle part of the bracket body 1 is respectively provided with a rectangular hole 2 and a rectangular hole 3 with a side longer than the opposite side and an arc-shaped line between the two sides. The bracket body 1 is made of aluminum alloy 6063 as a whole, and the right angle of the rectangular hole 2 is chamfered with an arc radius of 2mm. The overall structure is simple, can save a lot of raw materials, and has a long service life.

The above is only the preferred implementation of the utility model, so all equivalent changes or modifications made according to the structure, features and principles described in the scope of the utility model patent application are included in the scope of the utility model patent application.
